Category
7-inch high-definition display
S-XS-0104
Delivery:
EXW/FOB
Country of Origin:
CHINA
The display is widely applied in various transportation vehicles, including buses, school buses, commercial vehicles, trucks, engineering vehicles, fire trucks, and ships.
Quantity:
| No. | Technical Name | Technical Parameters |
| 1 | Display Device | TFT-LED Full-View Angle IPS Screen |
| 2 | Screen Size | 7 inches |
| 3 | External Terminals | S-Video Interface (AV1 Video, AV2 Video, AV3 Video, Power, Ground, CAM2 Power, CAM3 Power, Right-Turn/Reverse Signal)Reverse image locked on AV2, right-turn image locked on AV3 |
| 4 | Brightness | 600 nits |
| 5 | Resolution | 1024(H) x 600(V) |
| 6 | Viewing Angle | U: 85°/D: 85°, R/L: 85° |
| 7 | Contrast Ratio | 500:01:00 |
| 8 | Image Mode | 16:09 |
| 9 | Functions | Reverse Electronic Ruler/Reverse Delay/Independent Mirror Image |
| 10 | Video Input | CVBS/720P/960P/1080P Adaptive |
| 11 | Signal Recognition | CVBS/720P/960P/1080P Adaptive and Display |
| 12 | Power Protection | Reverse Polarity Protection Design, TVS Diode Protection Circuit |
| 13 | Anti-Interference Design | Anti-Interference Isolation Circuit (Optional) |
| 14 | Power Consumption | ≤10W at 12V (including camera) |
| 15 | Power Input | DC 12-32V |
| 16 | Net Weight | Approximately 400 grams |
| 17 | Dimensions | 186.8mm(W) x 108mm(H) x 29mm(T) |
